Autel MaxiCOM MK808BT Pro
The Autel MaxiCOM MK808BT Pro is an advanced automotive diagnostic tool that can quickly read and clear DTCs for a wide range of vehicle makes and models. As a pro-grade scanner, it offers a range of advanced features, including Oil Reset, EPB, SAS, BMS, ABS Brake Bleed, and DPF Regeneration. With its advanced functionality and user-friendly design, the MaxiCOM MK808BT Pro is a valuable tool for any professional mechanic or automotive enthusiast.
-

-
No IP Restriction, You can use MK808BT Pro all over the world.
-

-
Autel Scan Tool MK808BT Pro works well on 80+ car makes and models worldwide (1996 and newer)
-

-
MaxiCOM MK808BT Pro Scanner has up to 26 Reset service functions options
-

-
Autel MaxiCOM MK808BT Pro is an upgraded model of MK808BT, which has improved hardware.
-

-
Autel MK808BT Pro supports Active Test
-

-
Autel MaxiCOM MK808BT Pro comes with one year free software update.
-

-
Autel brand new authentic tool comes with 1-Year warranty
-

-
Autel MaxiCOM MK808BT Pro can switch multiple working languages, including German, Russian, etc.
-

-
No IP Restriction, You can use MK808BT Pro all over the world.
-

-
Autel Scan Tool MK808BT Pro works well on 80+ car makes and models
-

-
MaxiCOM MK808BT Pro Scanner has up to 26 Reset service functions options
-

-
Autel MaxiCOM MK808BT Pro is an upgraded model of MP808BT
-

-
Autel MK808BT Pro supports Active Test
-

-
MK808BT Pro comes with one-year software update
-

-
Autel brand new authentic tool comes with 1-Year warranty
-

-
Autel MK808BT Pro can switch multiple working languages
The Improvement of MK808BT Pro
Model |
MK808BT |
MK808BT Pro |
CPU |
ROCKCHIP RK3188 (1.4GHz) |
ROCKCHIP RK3566 (1.8GHz) |
RAM |
1GB |
4GB |
Android Version |
Android 4.4.4 |
Android 11 |
Wi-Fi |
2.4GHz |
2.4GHz & 5GHz |
Diagnostic
The Diagnostics tool MK808BT Pro's application can retrieve ECU information, read & erase DTCs, and view live data. The Diagnostics application can access the electronic control unit (ECU) for various vehicle control systems, including engine, transmission, antilock brake system (ABS), airbag system (SRS)
Vehicle Identification
The MaxiCOM diagnostic system (MK808BT Pro)supports four methods for Vehicle Identification: Auto VIN Scan, Manual VIN Input, Automatic Selection, Manual Selection
- Auto Scan
- ECU Information
- Trouble Codes
- Additional Functions
The Auto Scan function performs a comprehensive scanning over all the ECUs in the vehicle to locate systems’ faults and retrieve DTCs. An example of the Auto Scan interface is pictured below:
MK808BT Pro retrieves and displays the specific information for the tested control unit, including unit type, version numbers and other specifications.
When this function is selected, the screen displays the data list for the selected module. The items available for any control module vary from one vehicle to another. The parameters display in the order that they are transmitted by the ECM, so expect variation between vehicles
- Auto Scan
- ECU Information
- Trouble Codes
- Additional Functions
The Auto Scan function performs a comprehensive scanning over all the ECUs in the vehicle to locate systems’ faults and retrieve DTCs. An example of the Auto Scan interface is pictured below:
MK808BT Pro retrieves and displays the specific information for the tested control unit, including unit type, version numbers and other specifications.
-
Read Codes
Autel MaxiCOM MK808BT Pro retrieves and displays the DTCs from the vehicle’s control system. The Read Codes screen varies for each vehicle being tested. On some vehicles, freeze frame data can also be retrieved for viewing
-
Erase Codes
After reading the retrieved codes and making appropriate vehicle repairs, use thisfunction to erase vehicle codes.
When this function is selected, the screen displays the data list for the selected module. The items available for any control module vary from one vehicle to another. The parameters display in the order that they are transmitted by the ECM, so expect variation between vehicles
Service
The Service section is specially designed to provide you with quick access to the vehicle systems for various scheduled service and maintenance performances. The typical service operation screen is a series of menu driven executive commands. By following the on-screen instructions to select appropriate execution options, enter correct values or data, and perform necessary actions, the system will guide you through the complete performance for various service operations.
The reset service is not applicable to all models, and the models supported by different functions are different. If you need to know whether Autel diagnostic tools can support it, please contact us and inform us of
-
- Vehicle information (brand, model, model or VIN )
- Requirements (code reading, clearing code? Which one or several items of the reset service? Or more advanced functions).
- Contact us
-
- Vehicle information (brand, model, model or VIN )
- Requirements (code reading, clearing code? Which one or several items of the reset service? Or more advanced functions).
-
Bi-Directional Control
Autel Scanner, MaxiCOM MK808BT Pro comes with advanced bi-directional control (active test) function that allows mechanics determine the integrity of the system or parts by sending commands to a car with the tool and reading the data coming back from it. Such as ABS, window, door, solenoids, relay, switch, valves, sunroof, headlamps and etc.

Guided Function
The Guided Functions are advantaged with their easy operations. A guided functions is composed of multiple basic functions, freeing users from trouble such as looking up channel number and login code. Every guided function has detailed operation guidance and operating condition statement.

Autel MaxiCOM MK808BT Pro Helpful Service
-
Auto VIN – The diagnostic system features the latest VIN-based Auto VIN Scan function to identify CAN vehicles in just one touch, which allows the technician to quickly detect vehicles, scan all the diagnosable ECUs on every vehicle and run diagnostics on the selected system
-
Remote Desk – MK808BT Pro works with TeamViewer Quick Support to enable you to receive ad-hoc remote support from Autel’s support center, colleagues, or friends, by allowing them to control your tablet diagnostic tool on their PC.
-
Shop Manager – MaxiCOM MK808BT Pro owns an application that helps you deal with the daily workshop business and improve customer service by helping you manage the workshop information, customer information records, and much more.
-
Data Manager – MK808BT Pro Supports to store, print, and review the saved files.
-
Academy – Autel MaxiCOM MK808BT Pro provides tutorials and technical bulletins written by top-notch technicians and product experts
Autel MaxiCOM MK808BT Pro Additional Functions
Autel MaxiVideo MV108 Digital Inspection Camera
Autel Battery Tester BT506
- Bi-Directional Control
- Guided Function
- Helpful Service
- Additional Functions
Autel Scanner, MaxiCOM MK808BT Pro comes with advanced bi-directional control (active test) function that allows mechanics determine the integrity of the system or parts by sending commands to a car with the tool and reading the data coming back from it. Such as ABS, window, door, solenoids, relay, switch, valves, sunroof, headlamps and etc.
The Guided Functions are advantaged with their easy operations. A guided functions is composed of multiple basic functions, freeing users from trouble such as looking up channel number and login code. Every guided function has detailed operation guidance and operating condition statement.
-
Auto VINThe diagnostic system features the latest VIN-based Auto VIN Scan function to identify CAN vehicles in just one touch, which allows the technician to quickly detect vehicles, scan all the diagnosable ECUs on every vehicle and run diagnostics on the selected system
-
Remote Desk – MK808BT Pro works with TeamViewer Quick Support to enable you to receive ad-hoc remote support from Autel’s support center, colleagues, or friends, by allowing them to control your tablet diagnostic tool on their PC.
-
Shop Manager – MaxiCOM MK808BT Pro owns an application that helps you deal with the daily workshop business and improve customer service by helping you manage the workshop information, customer information records, and much more.
-
Data Manager –MK808BT Pro Supports to store, print, and review the saved files.
-
Academy -Autel MaxiCOM MK808BT Pro provides tutorials and technical bulletins written by top-notch technicians and product experts
Autel MaxiVideo MV108 Digital Inspection Camera
Autel Battery Tester BT506
Autel MaxiCOM MK808BT Pro Specification:
Operating System: |
Android 11 |
Processor: |
Cortex-A55 quad-core processor (1.8GHz) |
Memory: |
4GB RAM & 64GB ROM |
Display: |
7-inch LCD capacitive touchscreen with 1024x600 resolution |
Connectivity: |
Mini USB 2.0; USB2.0; Wi-Fi; HDMI Type A; Micro SD card slot(supports up to 32GB) |
Sensors; |
Light sensor for brightness auto changing |
Audio Input/Output: |
Input: N/A, Output: buzzer |
Power and Battery: |
3.7 V/5000 mAh lithium-polymer battery Charges via 5 VDC power supply |
Tested Battery Life: |
Around 7 hours of continuous use |
Battery Charging Input : |
5V/1.5A |
Power Consumption: |
600 mA(LCD on with default brightness, Wi-Fi on)@3.7 V |
Operating Temp.: |
0 to 55°C(32 to 131°F) |
Storage Temp.: |
-20 to 60°C (-4 to 140°F) |
Operating Humidity: |
5%-95% non-condensing |
Dimensions (W x H x D): |
237.8 mm (9.4”) x 148.6 mm (5.9”) x 35.5 mm (1.4”) |
Net Weight |
788 g (2.42 lb.) |
Protocols |
ISO9141-2, ISO14230-2, ISO15765, K/L-Line, Flashing Code, SAE-J1850 VPW, SAE-J1850PWM, SAE J2610,GM UART, Honda Diag-H Protocol, ISO11898 (Highspeed, Middlespeed, Lowspeed and Singlewire CAN, fault-tolerant CAN), UART Echo Byte Protocol, TP2.0, TP1.6 |
Benefits of Updating Your Tool to Latest
-
Tool Software/Function Upgrades: Get the latest features and functions as they roll out from Autel
-
Latest Vehicle Coverage: Service all the latest makes and models supported by Autel
How do we process your update service?
- After checkout, please send us your S/N and we will authorize your scanner within 24 hours.
- After authorizing, we will send you an notification and you will be able to renew your device online.
Please note: This update is very easy to operate, no shipping needed
Why buy update service from us?
We are Autel Authorized Dealer, we offer better price than others.
